| Quantity: | |
|---|---|
4x8 96x48 2440x1220 2400x1200 1800x1200
OEM
392020
2440 X 1220mm Corri Board Corriboard Sheet for Surface Protection Printing Signage Details
4x8 Temporary Polypropylene Corrugated Plastic Corriboard Sheets is also synonymous with Polypropylene Corrugated Sheet, Corrugated Plastic Sheets, Coroplast, Corflute, Correx, Corex, Danpla, Impraboard, Danpla, Corriboard, Fluteboard, Coreflute, Cartonplast, Twinwall Sheet or Hollow Profile Sheet etc., is co-extruded from polypropylene or polyethylene resin. Black Correx Polypropylene Corri Board Surface Floor Protection Sheet is widely used in construction protection, printing signs, industrial packing and customized packaging boxes etc.
For surface protection, Twin Wall Polypropylene Corrugated Plastic Corri Board Corriboard Sheets is easy to handle cost-effective for temporary surface protection, including packaging inserts, surface protection for floors, walls, windows and counters during construction. Corrugated Plastic Corriboard Floor Protector Sheet last longer, preventing frequent cardboard replacement. Polypropylene Fluted Plastic Corriboard Sheets are versatile and can be cut to size on-site to meet your specific business needs. Any size, any shape, 2400X1200 Polypropylene Correx Corri Boards can be cut, curved or creased to fit perfectly any feature which needs 100% protection. We also offer a custom print service so you can add your own logo.
4x8 Polypropylene Corriboard Sheet for flooring covering sheet or roll does not have the Corona treatment and is generally 2mm, 2.5mm or 3mm 5mm thick much more. Usually black, although also available in white or blue, in either 1800mm x 1200mm or 2400mm x 1200mm or others.
2440 X 1220mm Corri Board Corriboard Sheet for Surface Protection Printing Signage Data Sheet:
Item | Unit | Thickness ＆ Physical Performance Parameter | ||||||||
2mm | 3mm | 4mm | 5mm | 6mm | 7mm | 8mm | 9mm | 10mm | ||
Raw Material | PP＆PE | PP＆PE | PP＆PE | PP＆PE | PP＆PE | PP＆PE | PP＆PE | PP＆PE | PP＆PE | |
Gram per Square Meter | GSM | 400 | 450 | 700 | 800 | 1200 | 1400 | 1600 | 1800 | 2000 |
Tension Fracture | N | ≥200 | ≥250 | ≥300 | ≥350 | ≥400 | ≥450 | ≥500 | ≥550 | ≥600 |
Elongation at Break | % | ≥50 | ≥50 | ≥50 | ≥50 | ≥50 | ≥50 | ≥50 | ≥50 | ≥50 |
Horizontal Compression Ratio | N | ≥700 | ≥900 | ≥1000 | ≥2500 | ≥3000 | ≥3500 | ≥4000 | ≥4500 | ≥5000 |
Vertical Compression Ratio | N | ≥90 | ≥150 | ≥350 | ≥600 | ≥600 | ≥700 | ≥750 | ≥800 | ≥1000 |
Tearing Force | N | ≥50 | ≥60 | ≥70 | ≥80 | ≥100 | ≥150 | ≥160 | ≥180 | ≥210 |
Available in Customized 2440 X 1220mm Corri Board Corriboard Sheet :
· UV Resistant
· Anti-Static Grade
· ESD Conductive
· Corona Treatment
· Fire Retardant (UL94)
· Ultra-Sonic & Heat Welding
· Edge Sealed and Round Corners
2440 X 1220mm Corri Board Corriboard Sheet for Surface Protection Printing Signage Benefits :
· Ideal for Green and Sustainability Programs
· Temporary clean-room protection
· Granite & Marble countertop templates
· Protection of walls, floors and architectural features of all types
· Stairs and columns
· Subsoil protection applications
· Form work – a great alternative to plywood
· Waterproofing Membranes
· Enclosures/Partitions
· Available in sheets or rolls
· Concrete protection and as a barrier to water and rock penetration
· Color: White, Black, Clear, Grey, Blue, Green, Yellow, Red, Pink, Purple etc.
· Other sizes can be manufactured to order depending on volume required.
2440 X 1220mm Corri Board Corriboard Sheet for Surface Protection Printing Signage Details
4x8 Temporary Polypropylene Corrugated Plastic Corriboard Sheets is also synonymous with Polypropylene Corrugated Sheet, Corrugated Plastic Sheets, Coroplast, Corflute, Correx, Corex, Danpla, Impraboard, Danpla, Corriboard, Fluteboard, Coreflute, Cartonplast, Twinwall Sheet or Hollow Profile Sheet etc., is co-extruded from polypropylene or polyethylene resin. Black Correx Polypropylene Corri Board Surface Floor Protection Sheet is widely used in construction protection, printing signs, industrial packing and customized packaging boxes etc.
For surface protection, Twin Wall Polypropylene Corrugated Plastic Corri Board Corriboard Sheets is easy to handle cost-effective for temporary surface protection, including packaging inserts, surface protection for floors, walls, windows and counters during construction. Corrugated Plastic Corriboard Floor Protector Sheet last longer, preventing frequent cardboard replacement. Polypropylene Fluted Plastic Corriboard Sheets are versatile and can be cut to size on-site to meet your specific business needs. Any size, any shape, 2400X1200 Polypropylene Correx Corri Boards can be cut, curved or creased to fit perfectly any feature which needs 100% protection. We also offer a custom print service so you can add your own logo.
4x8 Polypropylene Corriboard Sheet for flooring covering sheet or roll does not have the Corona treatment and is generally 2mm, 2.5mm or 3mm 5mm thick much more. Usually black, although also available in white or blue, in either 1800mm x 1200mm or 2400mm x 1200mm or others.
2440 X 1220mm Corri Board Corriboard Sheet for Surface Protection Printing Signage Data Sheet:
Item | Unit | Thickness ＆ Physical Performance Parameter | ||||||||
2mm | 3mm | 4mm | 5mm | 6mm | 7mm | 8mm | 9mm | 10mm | ||
Raw Material | PP＆PE | PP＆PE | PP＆PE | PP＆PE | PP＆PE | PP＆PE | PP＆PE | PP＆PE | PP＆PE | |
Gram per Square Meter | GSM | 400 | 450 | 700 | 800 | 1200 | 1400 | 1600 | 1800 | 2000 |
Tension Fracture | N | ≥200 | ≥250 | ≥300 | ≥350 | ≥400 | ≥450 | ≥500 | ≥550 | ≥600 |
Elongation at Break | % | ≥50 | ≥50 | ≥50 | ≥50 | ≥50 | ≥50 | ≥50 | ≥50 | ≥50 |
Horizontal Compression Ratio | N | ≥700 | ≥900 | ≥1000 | ≥2500 | ≥3000 | ≥3500 | ≥4000 | ≥4500 | ≥5000 |
Vertical Compression Ratio | N | ≥90 | ≥150 | ≥350 | ≥600 | ≥600 | ≥700 | ≥750 | ≥800 | ≥1000 |
Tearing Force | N | ≥50 | ≥60 | ≥70 | ≥80 | ≥100 | ≥150 | ≥160 | ≥180 | ≥210 |
Available in Customized 2440 X 1220mm Corri Board Corriboard Sheet :
· UV Resistant
· Anti-Static Grade
· ESD Conductive
· Corona Treatment
· Fire Retardant (UL94)
· Ultra-Sonic & Heat Welding
· Edge Sealed and Round Corners
2440 X 1220mm Corri Board Corriboard Sheet for Surface Protection Printing Signage Benefits :
· Ideal for Green and Sustainability Programs
· Temporary clean-room protection
· Granite & Marble countertop templates
· Protection of walls, floors and architectural features of all types
· Stairs and columns
· Subsoil protection applications
· Form work – a great alternative to plywood
· Waterproofing Membranes
· Enclosures/Partitions
· Available in sheets or rolls
· Concrete protection and as a barrier to water and rock penetration
· Color: White, Black, Clear, Grey, Blue, Green, Yellow, Red, Pink, Purple etc.
· Other sizes can be manufactured to order depending on volume required.
